Wig Wag Light with Mounting Bracket

A Wig Wag strobe is used for extra visibility for a Road Pilot vehicle.

Features:

• High output, wide viewing angle.
• Up to 26 flash patterns.
• Dimming function.
• Multiple mounting options.
• Low current draw.
• Can be synchronised.
• Virtually unlimited colour combinations are available (upon request).
• Epoxy-encapsulated electronics for environmental & vibration protection.
• LEDs are rated to 100,000 hours of operation.
• Multi-voltage.
• 5-year warranty.

Wig Wag lights must:

• be mounted in pairs, one on each side of the front of the vehicle; and
• flash an alternating white light; and
• not interfere with the amber warning lights or any other lights required under road law; and
• not be headlights; and
• have an illuminating surface area not less than 40cm²; and
• be no less than 500mm above ground level and no more than 1000mm above ground level.

Wig Wag lights may be:

• spotlights with a maximum output of 55 watts, provided they are angled down 45 degrees toward the road surface; or LED day running lights (as per ADR 76), provided the light emitted from each lamp does not exceed 400cd.
