Fire Resistant Anti-Static Spiral Wrap

FRAS (Fire-Resistant Anti-Static) Hydraulic Hose Spiral Wrap protects hydraulic lines against abrasion, cuts, crushing, UV and various hazards which can destroy expensive hose and cable assemblies and cause output to suffer due to downtime. Gadi Hose Protection has a wide range of hydraulic hose spiral wraps. It can be colour-coded for aesthetics and in some applications for ease of identification.

Fire Resistant Anti-Static (FRAS) Spiral Wrap is produced from a conductive thermoplastic compound on a polyethylene base. A special conductive carbon black is used for conductivity. In addition to being flame retardant, these wraps are designed to have low electrical resistance, helping to prevent hydraulic hose and cable bundles from building up an electrical charge. Tested to: AS 2600, AS 1180.10B, AS 1180.13A and MSHA # IC-264/0 standards.

Why choose Gadi Hose Protection’s FRAS Spiral Wrap?

• It is Australian-made.
• Flame retardant.
• Low electrical resistance.
• FRAS Wrap prevents hoses and cable bundles from building up an electrical charge.
• Right-hand cut.
• Tight coils for minimal hose exposure.
• A wide range of sizes suits most hose diameters.
• Developed to increase the service life of hydraulic hoses.
• It is manufactured from a conductive thermoplastic compound on a polyethylene base
• Unique rounded edges make installing and reducing the risk of exposed sharp edges easy.
• Can be used to protect a single hose or to bundle hoses/cables together.
• Resistant to chemical attack and suitable for use in the most aggressive environments. Suitable for use with all hydraulic fluids including glycol and phosphate ester-based products.
• Suitable for use with equipment operating across a wide temperature range (-75 C to 123 C).
• All wall thicknesses have A +/- tolerance.
• All sizes are nominal.
• The standard colour is Black.
• Tested to AS 2600, AS 1180.10B, AS 1180.13A and MSHA # IC-264/0 Standards

FAQs

How much hydraulic hose spiral wrap do I need to buy? You need to allow 20% more spiral wrap length than the length of the hydraulic hose.

How long do hydraulic hoses last? Answers vary on the treatment of the machine and hoses. Machines regularly maintained and looked after whilst operating can have hydraulic hoses lasting over two years (on average). If the machine is in a rougher environment then the hydraulic hose may last up to 1-2 years.

Why has my hydraulic hose burst? There are many reasons why hydraulic hoses can burst, the most common reasons are kinks in the hose, abrasion, crushing or extension pressure and pulling.

What are the dangers of a hydraulic hose bursting? There are many risks associated with hydraulic hoses bursting, not only to life and limb in the immediate vicinity but can also cause a fire if the oil comes into contact with a hot surface such as exhaust manifolds.
